Quick spec of N9K-C93108TC-EX

• Part Number : N9K-C93108TC-EX
• Ports : 48 x 10GBASE-T and 6 x 40/100-Gbps QSFP28 ports
• Downlink supported speeds : 100-Mbps and 1/10-Gbps speeds
• CPU : 4 cores
• System memory : 24 GB
• SSD drive : 64 GB
• System buffer : 40 MB
• Management ports : 2 ports: 1 RJ-45 and 1 SFP
• USB ports : 1
• RS-232 serial ports : 1
• Power supplies (up to 2) : 650W AC, 930W DC, or 1200W HVAC/HVDC
• Typical power (AC/DC) : 290W
• Maximum power (AC/DC) : 499W
• Physical dimensions (H x W x D) : 1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm)
• Weight (without power supplies or fans) : 17.7 lb (8.0 kg)

N9K-C93108TC-EX  Specification

• Ports :48 x 10GBASE-T and 6 x 40/100-Gbps QSFP28 ports
• Downlink supported speeds :100-Mbps and 1/10-Gbps speeds
• CPU :4 cores
• System memory :24 GB
• SSD drive :64 GB
• System buffer :40 MB
• Management ports :2 ports: 1 RJ-45 and 1 SFP
• USB ports :1
• RS-232 serial ports :1
• Power supplies (up to 2) :650W AC, 930W DC, or 1200W HVAC/HVDC
• Typical power (AC/DC) :290W
• Maximum power (AC/DC) :499W
• Input voltage (AC) :100 to 240V
• Input voltage (high-voltage AC [HVAC]) :200 to 277V
• Input voltage (DC) :–48 to –60V
• Input voltage (high-voltage DC [HVDC]) :–240 to –380V
• Frequency (AC) :50 to 60 Hz
• Fans :4
• Airflow :Port-side intake and exhaust
• Physical dimensions (H x W x D) :1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm)
• Acoustics :48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dBA at 100% fan speed
• RoHS compliance :Yes
• MTBF :366,130 hours
• Maximum number of Longest Prefix Match (LPM) routes :896,000
• Maximum number of IP host entries :896,000
• Maximum number of MAC address entries :256,000
• Maximum number of multicast routes :32,000
• Number of Interior Gateway Management Protocol (IGMP) snooping groups :Shipping: 8,000 Maximum: 32,000
• Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch :16
• Maximum number of Access Control List (ACL) entries :Per slice of the forwarding engine: 4000 ingress 2000 egress Total (2 forwarding slices): 8000 ingress 4000 egress
• Maximum number of VLANs :3,967
• Number of Virtual Routing and Forwarding (VRF) instances :Shipping: 1,000 Maximum: 16,000
• Maximum number of ECMP paths :64
• Maximum number of port channels :512
• Maximum number of links in a port channel :32
• Number of active SPAN sessions :4
• Maximum number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances :3,967
• Maximum number of Hot-Standby Router Protocol (HSRP) groups :490
• Number of Network Address Translation (NAT) entries :1,023
• Maximum number of Multiple Spanning Tree (MST) instances :64
• Flow-table size used for Cisco Tetration Analytics platform :64,000
• Operating temperature :32 to 104°F (0 to 40°C)
• Nonoperating (storage) temperature :–40 to 158°F (–40 to 70°C)
• Humidity :5 to 95% (noncondensing)
• Altitude :0 to 13,123 ft (0 to 4000m)
• Weight (without power supplies or fans) :17.7 lb (8.0 kg)
