NEW Cisco Meraki MS355-48X-HW 32x RJ-45 16x PoE RJ-45 2x QSFP+ Unclaimed Switch

(No reviews yet) Write a Review
MPN:
MS355-48X-HW
Condition:
New
Shipping:
Calculated at Checkout
  • Network Ports : 32x 1 Gigabit Ethernet RJ-45, 16x 10 Gigabit Ethernet PoE RJ-45
    Uplink Ports : 2x 40 Gigabit Ethernet QSFP+
    Stacking Ports : 2x 100G Stacking Ports
    Stacking Bandwidth : 400 Gbps
    Fan Modules AirFlow Direction : 3x Pre Installed Fans
    Power Supplies Included : 1x MA-PWR-1025WAC PSU Included - 2x Slots - 2nd PSU ordered separately
    PoE Budget : 740W Optional PoE
    Switching Capacity : 544 Gbps
    Forwarding Rate : 405 mpps
    MAC Address Table Size : 32,000
    Rack Mounts : Included (1-RU)
    Model Number : MS355-48X-HW
    Part Number : MS355-48X-HW, MS355-48X-HW=, MS355-48X-HW-WS
    Condition : New
  • Network Ports : 32x 1 Gigabit Ethernet RJ-45, 16x 10 Gigabit Ethernet PoE RJ-45
    Uplink Ports : 2x 40 Gigabit Ethernet QSFP+
    Stacking Ports : 2x 100G Stacking Ports
    Stacking Bandwidth : 400 Gbps
    Fan Modules AirFlow Direction : 3x Pre Installed Fans
    Power Supplies Included : 1x MA-PWR-1025WAC PSU Included - 2x Slots - 2nd PSU ordered separately
    PoE Budget : 740W Optional PoE
    Switching Capacity : 544 Gbps
    Forwarding Rate : 405 mpps
    MAC Address Table Size : 32,000
    Rack Mounts : Included (1-RU)
    Model Number : MS355-48X-HW
    Part Number : MS355-48X-HW, MS355-48X-HW=, MS355-48X-HW-WS
    Condition : New
$5,999.00
Frequently bought together:

Description

NEW Cisco Meraki MS355-48X-HW 32x RJ-45 16x PoE RJ-45 2x QSFP+ Unclaimed Switch

Overview

The Cisco Meraki MS355-48X-HW is designed for demanding enterprise and campus environments, providing high-bandwidth access switching with advanced features and cloud-based managemet.The Cisco Meraki MS355 series provides full 10G multi-gigabit (mGig) access switching for demanding enterprise and campus environments. The switch series features a high mGig port density for 802.11ax wireless access points, servers, and workstations. The family supports 40G or 10G uplinks, physical stacking, up to 60W of port power with UPoE, and field replaceable power supplies/fans. All Meraki switches are managed through an elegant, intuitive cloud-based interface, rather than cryptic command line. Available models with up to 24 full 10G mGig ports for 802.11ax access points, servers, and workstations • Multi-gigabit (mGig) ports support 100M/1/2.5/5/10G of bandwidth over copper cabling • Access switching with up to 48 ports and 740W of UPoE support • 40G or 10G uplink interfaces on all models • Dual stacking interfaces with 400 Gbps of bandwidth • Support for field replaceable, redundant power supplies • Up to 688 Gbps of switching capacity • 6 configurable QoS queues for converged voice, video, and data applications • Integrated mounting brackets for rack mounting • Lifetime hardware warranty and advanced replacement at no additional cost

Specifications

  • Network Ports : 32x 1 Gigabit Ethernet RJ-45, 16x 10 Gigabit Ethernet PoE RJ-45
  • Model: MS355-48X-HW
  • Dimensions: 1.72” x 19.08” x 20.34” (4.37 x 48.46 x 51.66 cm)
  • Weight: 13.00 lb (5.90 kg)
  • Port Configuration:
    • 16 x mGig Ports: These support 100M/1G/2.5G/5G/10G bandwidth over copper cabling.
    • 32 x 1G Ethernet RJ45 Ports
    • 2 x 40G QSFP+ or 4 x 10G SFP+ Uplinks
    • 2 x 100G QSFP28 Stacking Ports
  • Switching Capacity: 544 Gbps
  • Stacking Bandwidth: 400 Gbps
  • Power over Ethernet (PoE): Supports up to 740W of UPoE (Universal Power over Ethernet) for devices like access points and cameras.
  • Quality of Service (QoS): Provides 6 configurable QoS queues for converged voice, video, and data applications.
  • Security Features:
    • IEEE 802.1X, MAB, and Hybrid Authentication: Wired access control with RADIUS server monitoring.
    • ACL Support (IPv4 & IPv6) and MAC whitelisting.
  • Management: All Meraki switches are managed through an elegant, intuitive cloud-based interface, eliminating the need for cryptic command-line configurations. The dashboard provides granular visibility into your network, including configuration changes, event logs, and more.
  • Additional Features:
    • Automatic Email Alerts: Receive alerts for power loss, downtime, Layer 1 errors, or configuration changes.
    • Remote Diagnostic Tools: Packet capture for troubleshooting network issues.
    • Role-Based Administration: Control access based on roles.
    • Zero-Touch Provisioning: Rapid deployment across sites.
    • Virtual Stacking: Configure switch ports via the dashboard without physical stacking.
    • Network Transparency: Detailed visibility into applications, operating systems, clients, and hostnames.
  • Part Number : MS355-48X-HW
  • Condition : New
