Cisco PWR-C1-1100WAC Catalyst 3850 Series 1100W AC Switch Power Supply

Quick spec of PWR-C1-1100WAC-Ref

• Product Code : PWR-C1-1100WAC
• Power supply rated maximum : 1100W
• Total output BTU (Note: 1000 BTU/hr = 293W) : 3793 BTU/hr, 1100W
• Input-voltage range and frequency : 115-240VAC, 50-60 Hz
• Input current : 12-6A
• Output ratings : -56V at 19.64A
• Output holdup time : 10 ms minimum at 102.5VAC
• Power-supply input receptacles : IEC 320-C16 (IEC60320-C16)
• Power cord rating : 13A
• Physical specifications : (H x W x D): 1.58 X 3.25 X 13.7 in

PWR-C1-1100WAC-Ref Specification

• Power supply rated maximum :1100W
• Total output BTU (Note: 1000 BTU/hr = 293W) :3793 BTU/hr, 1100W
• Input-voltage range and frequency :115-240VAC, 50-60 Hz
• Input current :12-6A
• Output ratings :-56V at 19.64A
• Output holdup time :10 ms minimum at 102.5VAC
• Power-supply input receptacles :IEC 320-C16 (IEC60320-C16)
• Power cord rating :13A
• Physical specifications :(H x W x D): 1.58 X 3.25 X 13.7 in
• Operating temperature :23 to 113°F (-5 to 45°C)
• Storage temperature :-40 to 158°F (-40 to 70°C)
• Relative humidity operating and nonoperating noncondensing :5 to 90% noncondensing
• Altitude :10,000 ft. (3000 meters), up to 45°C
• MTBF :Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
• EMI and EMC compliance :FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55022 Class A CISPR 22 Class A AS/NZS 3548 Class A BSMI Class A (AC input models only) VCCI Class A EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
• Safety compliance :UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
• LED indicators :“AC OK”: Input power to the power supply is OK “PS OK”: Output power from the power supply is OK
