Cisco N9K-C9336C-FX2 32 100GB QSFP28 Front-to-Back Airflow Switch
- MPN:
- N9K-C9336C-FX2
- Shipping:
- Free Shipping
Frequently bought together:
Description
Cisco N9K-C9336C-FX2 Nexus 9300-FX 32x 100GB QSFP28 Back-to-Front Airflow Switch
N9K-C9336C-FX2 Overview
Cisco Nexus 9300-FX2 series is an extension of Nexus 9300-FX series switches with higher bandwidth capacity. The switches offer a variety of interface options to transparently migrate existing data centers from 1-Gbps, and 10-Gbps speeds to 25- Gbps at the server, and from 10- and 40-Gbps speeds to 50- and 100- Gbps at the aggregation layer. The platforms provide investment protection for customers, delivering large buffers, highly flexible Layer 2 and Layer 3 scalability, and performance to meet the changing needs of virtualized data centers and automated cloud environments.
Quick spec of N9K-C9336C-FX2
- Product Code : N9K-C9336C-FX2
- Ports : 36 x 40/100-Gbps QSFP28 ports
- Supported speeds : 1/10/25/40/100-Gbps Ethernet Breakout supported on all ports, 1-36: 100G, 2x50G NRZ, 40G native, 4x10/25G (10G w/QSA) 1G w/QSA except ports 1-6 and 33-36
- CPU : 4 cores
- System memory : 24 GB
- SSD drive : 128 GB
- System buffer : 40 MB
N9K-C9336C-FX2 Specification
- Item :Cisco Nexus 9300-FX2 Series Switches
- Feature :Cisco Nexus 9336C-FX2
- Ports :36 x 40/100-Gbps QSFP28 ports
- Supported speeds :1/10/25/40/100-Gbps Ethernet Breakout supported on all ports, 1-36: 100G, 2x50G NRZ, 40G native, 4x10/25G (10G w/QSA) 1G w/QSA except ports 1-6 and 33-36
- CPU :4 cores
- System memory :24 GB
- SSD drive :128 GB
- System buffer :40 MB
- Management ports :2 ports: 1 RJ-45 and 1 SFP+
- USB ports :1
- RS-232 serial ports :1
- Power supplies(up to 2) :750W AC, 1100W AC, 1100W DC, 1100W HVAC/HVDC
- Typical power (AC) :337W
- Maximum power (AC) :719W
- Input voltage (AC) :100 to 240V
- Input voltage (High-Voltage AC [HVAC]) :100 to 277V
- Input voltage (DC) :–40 to –72V
- Input voltage (High-Voltage DC [HVDC]) :–240 to –380V
- Frequency (AC) :50 to 60 Hz
- Fans :3 dual fan trays
- Airflow :Port-side intake and exhaust
- Physical dimensions(H x W x D) :1.72 x 17.3 x 24.5 in. (4.4 x 43.9 x 62.3 cm)
- MTBF :352,590 hours
- Maximum number of Longest Prefix Match (LPM) routes** :896,000
- Maximum number of IP host entries** :896,000
- Maximum number of MAC address entries** :256,000
- Maximum number of multicast routes :128,000
- Number of Interior Gateway Management Protocol (IGMP) snooping groups :Shipping: 8,000 Maximum: 32,000
- Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch :16
- Maximum number of Access Control List (ACL) entries :Per slice of the forwarding engine: 5000 ingress 2000 egress
- Maximum number of VLANs :4096
- Number of Virtual Routing and Forwarding (VRF) instances :Shipping: 1,000 Maximum: 16,000
- Maximum number of ECMP paths :64
- Maximum number of port channels :512
- Maximum number of links in a port channel :32
- Number of active SPAN sessions :4
- Maximum number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances :3,967
- Maximum number of Hot-Standby Router Protocol (HSRP) groups :490
- Number of Network Address Translation (NAT) entries :1,023
- Maximum number of Multiple Spanning Tree (MST) instances :64
- Flow-table size used for Cisco Tetration Analytics platform :64,000
- Number of Queues :8
