Cisco Meraki MS425-16-HW 16x 10GB FC SFP+ 2x 40GB QSFP+ Unclaimed Switch

Quick spec of MS425-16-HW-ref

• SKU : MS425-16-HW
• Interfaces : • 16x 10 GbE SFP+ Fiber • 2 × 40GbE QSFP+ uplink/stacking ports • RJ45 Management port
• Switching capacity : 480 Gbps
• Idle/Full Load Power : 98W/136 W
• What’s Included : 1 x Power Supply (MA-PWR-250WAC), Mounting screw kit, 3 x Pre-Installed Fans
• Dimensions : 19.1 x 20.3 x 1.7” (48.5 x 51.6 x 4.4 CM)
• Weight : 13.7lb (6.2kg)

MS425-16-HW-ref Specification

• Interfaces :• 16x 10 GbE SFP+ Fiber • 2 × 40GbE QSFP+ uplink/stacking ports • RJ45 Management port
• Switching capacity :480 Gbps
• Idle / Full Load Power :98W/136 W
• Power Supply Configuration :Hot-swappable
• Supported Power Supply :2 x 250W PSU
• What’s included :1 x Power Supply (MA-PWR-250WAC), Mounting screw kit, 3 x Pre-Installed Fans
• Dimensions :19.1 x 20.3 x 1.7” (48.5 x 51.6 x 4.4 CM)
• Weight :13.7lb (6.2kg)
• Management :• Managed via the Web with the Meraki cloud management platform • Integrated with Meraki Wireless and complete portfolio of IT products and solutions • Zero-touch remote provisioning (no staging needed) • Detailed historical per-port and per-client usage statistics • DHCP, client, and hostname fingerprinting • SNMPd and SYSLOG support for integration with other network management solutions • Automatic firmware upgrades with scheduling control • Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
• Layer 3 :• Static routing • DHCP helper • DHCP server • Open shortest path first (OSPF v2) • Warm spare for L3 gateway redundancy • Automatic DHCP failover in warm spare mode
• Remote Diagnostics :• Email, SMS and Mobile push notification alerts • Cable testing and link failure detection with alerting • Live remote packet capture • Dynamic and interactive network discovery and topology
• Power :• Power input: 100 - 240 VAC, 47-63 Hz • Power consumption at idle: 98W • Power consumption full load: 136W
• Stacking :• Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration • Flexible stacking on all interfaces and QSFP+/SFP+/SFP accessory types, up to 8 switches
• Ethernet Switching Capabilities :• 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping) • 802.1Q VLAN and trunking support for up to 4,094 VLANs • 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP) • Broadcast storm control • 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP) • 802.3ad Link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switches • Port mirroring • IGMP snooping for multicast filtering • MAC forwarding entries: 128K
• Environment :• Operating temperature: 0°C to 40°C • Humidity: 5 to 95% non-condensing
• Regulatory :• CSA-US (US, Canada) • FCC (USA) • IC (Canada) • CE (Europe) • RoHS
• Mounting :• Rack-mountable with included rack mount hardware • Front-to-back airflow
• MTBF Ratings :284,423 hrs
