Cisco
Cisco Firepower 3140 NGFW Appliance
- MPN:
- FPR3140-ASA-K9
- Condition:
- New
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Cisco Firepower 3140 NGFW Appliance
FPR3140-ASA-K9 Overview
The enterprise-class Cisco Secure Firewall 3100 Series supports your evolving world. It makes hybrid work and zero trust practical, with the flexibility to ensure strong return on investment. The Cisco Secure Firewall 3100 Series is a family of four threat-focused security appliances that delivers business resiliency and superior threat defense. Each model offers outstanding performance for multiple firewall use cases, even when advanced threat functions are enabled. These performance capabilities are enabled by a modern CPU architecture coupled with purpose-built hardware that optimizes firewall, cryptographic, and threat inspection functions.
FPR3140-ASA-K9 Specifications
| Cisco Firepower 3000 Series Summary | |||||
|---|---|---|---|---|---|
| Secure Firewall Models | Firewall | FW+AVC+IPS | IPS Throughput | Interfaces | Optional interfaces |
| 3140 | 49G | 45G | 45G | 8 x RJ45, 8 x 1/10/25G SFP+ | 10G/25G/40G SFP+, 4x40G NM |
| Cisco Firepower 3000 Series Performance Specifications | |
|---|---|
| Features | 3140 |
| Throughput: FW + AVC (1024B) | 45.0 Gbps |
| Throughput: FW + AVC + IPS (1024B) | 45.0 Gbps |
| Maximum concurrent sessions, with AVC | 10 million |
| Maximum new connections per second, with AVC | 300,000 |
| TLS1 | 11.5 Gbps |
| Throughput: IPS (1024B) | 45.0 Gbps |
| IPSec VPN Throughput (1024B TCP w/Fastpath) |
22.4 Gbps |
| Projected IPSec VPN Throughput (1024B TCP w/Fastpath) with VPN Offload (FTD 7.2) |
39.4 Gbps |
| Maximum VPN Peers | 20,000 |
| Local On-device Management | Yes |
| Centralized management | Centralized configuration, logging, monitoring, and reporting are performed by the Firewall Management Center or alternatively in the cloud with Cisco Defense Orchestrator |
| Application Visibility and Control (AVC) | Standard, supporting more than 4000 applications, as well as geolocations, users, and websites |
| AVC: OpenAppID support for custom, open source, application detectors | Standard |
| Cisco Security Intelligence | Standard, with IP, URL, and DNS threat intelligence |
| Cisco Secure IPS | Available; can passively detect endpoints and infrastructure for threat correlation and Indicators of Compromise (IoC) intelligence |
| Cisco Malware Defense | Available; enables detection, blocking, tracking, analysis, and containment of targeted and persistent malware, addressing the attack continuum both during and after attacks. Integrated threat correlation with Cisco Secure Endpoint is also optionally available |
| Cisco Secure Malware Analytics | Available |
| URL Filtering: number of categories | More than 80 |
| URL Filtering: number of URLs categorized | More than 280 million |
| Automated threat feed and IPS signature updates | Yes: class-leading Collective Security Intelligence (CSI) from the Cisco Talos Group |
| Third-party and open-source ecosystem | Open API for integrations with third-party products; Snort® and OpenAppID community resources for new and specific threats |
| High availability and clustering | Active/active, Active/standby. Cisco Secure Firewall 3100 Series allows clustering of up to 8 chassis |
| Cisco Trust Anchor Technologies | Secure Firewall 3100 Series platforms include Trust Anchor Technologies for supply chain and software image assurance. Please see the section below for additional details |
| Cisco Firepower 3000 Series ASA Performance and Capabilities | |
|---|---|
|
Features |
3140 |
| Stateful inspection firewall throughput1 | 49.0 Gbps |
| Stateful inspection firewall throughput (multiprotocol)2 | 43.0 Gbps |
| Concurrent firewall connections | 10 million |
| New connections per second | 1,100,000 |
| IPsec VPN throughput (450B UDP L2L test) |
17 Gbps |
| Projected IPsec VPN throughput (450B UDP L2L test) with VPN Offload (ASA 9.18) |
33.0 Gbps |
| Maximum VPN Peers | 20,000 |
| Security contexts (included; maximum) | 2; 100 |
| High availability | Active/active and active/ standby |
| Clustering | 8 |
| Scalability | VPN Load Balancing |
| Centralized management | Centralized configuration, logging, monitoring, and reporting are performed by Cisco Security Manager or alternatively in the cloud with Cisco Defense Orchestrator |
| Adaptive Security Device Manager | Web-based, local management for small-scale deployments |
| Cisco Firepower 3000 Series Hardware Specifications | |
|---|---|
| 3140 | |
| Dimensions (H x W x D) | 1.75 x 17 x 20 in. (4.4 x 43.3 x 50.8 cm) |
| Form factor (rack units) | 1RU |
| Integrated I/O | 8 x 10M/100M/ 1GBASE-T Ethernet interfaces (RJ- 45), 8 x 1/10/25 Gigabit (SFP) Ethernet interfaces |
| Network modules | 8 x 1/10/25G, 4 x 40G Options, |
| Maximum number of interfaces | Up to 24 total Ethernet ports (8x1G RJ-45, 8x1/10/25G SFP, and network module) |
| Integrated network management ports | 1 x 1/10G SFP |
| Serial port | 1 x RJ-45 console |
| USB | 1 x USB 3.0 Type-A (900mA) |
| Storage | 1x 900 GB, 1x spare slot |
| Power supply configuration | Dual 400W AC. Single/dual 400W DC optional1 |
| AC input voltage | 100 to 240V AC |
| AC maximum input current | <6A at 100V |
| AC maximum output power | 400W |
| AC frequency | 50 to 60 Hz |
| AC efficiency | <89% at 50% load |
| DC input voltage | -48V to -60VDC |
| DC maximum input current | <12.5A -48V |
| DC maximum output power | 400W |
| DC efficiency | <88% at 50% load |
| Redundancy | 1+1 or DC with dual supplies |
| Fans | 2 hot-swappable fan modules (with 2 fans each)2 |
| Noise | 65 dBA@ 25C 74 dBA maximum |
| Rack mountable | Yes. Fixed mount brackets optional. (2- post). Mount rails included (4-post EIA- 310-D rack) |
| Weight | 25 lb (11.4 kg) 2 x power supplies, 1 x NM, fan module, 1x SSD |
| Temperature: operating | 32 to 104°F (0 to 40°C) |
| Temperature: nonoperating | -4 to 149°F (-20 to 65°C) |
| Humidity: operating | 10 to 85% noncondensing |
| Humidity: nonoperating | 5 to 95% noncondensing |
| Altitude: operating | 10,000 ft (max) |
| Altitude: nonoperating | 40,000 ft (max) |
| NEBS operation (FPR- 3120 Only)3 | Operating altitude: 0 to 13,000 ft (3962 m) Operating temperature: Long term: 0 to 45°C, up to 6,000 ft (1829 m) Long term: 0 to 35°C, 6,000 to 13,000 ft (1829 to 3964 m) Short term: -5 to 55°C, up to 6,000 ft (1829 m) |
