Cisco Business CBS350-48FP-4X Managed Switch 48 Port GE PoE Switch New Sealed

Quick spec of CBS350-48FP-4X-New

• Product Code : CBS350-48FP-4X
• Capacity in Millions of Packets per Second (mpps) (64-byte packets) : 130.94
• Switching Capacity in Gigabits per Second (Gbps) : 176.0
• Total System Ports : 48 Gigabit Ethernet +4 x 10G
• RJ-45 Ports : 48 x Gigabit Ethernet
• Combo Ports (RJ45 + Small form-factor pluggable [SFP]) : 4 x SFP+
• Packet Buffer : 3 MB

CBS350-48FP-4X-New Specification

• Feature :Description
• Capacity in Millions of Packets per Second (mpps) (64-byte packets) :130.94
• Switching Capacity in Gigabits per Second (Gbps) :176.0
• Total System Ports :48 Gigabit Ethernet +4 x 10G
• RJ-45 Ports :48 x Gigabit Ethernet
• Combo Ports (RJ45 + Small form-factor pluggable [SFP]) :4 x SFP+
• Packet Buffer :3 MB
• Unit dimensions (W x D x H) :445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)
• IPv4 routing :Wirespeed routing of IPv4 packets Up to 990 static routes and up to 128 IP interfaces
• IPv6 routing :Wirespeed routing of IPv6 packets
• Layer 3 Interface :Configuration of Layer 3 interface on physical port, Link Aggregation (LAG), VLAN interface, or loopback interface
• Classless Interdomain Routing (CIDR) :Support for classless interdomain routing
• RIP v2 :Support for Routing Information Protocol version 2 for dynamic routing
• Policy-Based Routing (PBR) :Flexible routing control to direct packets to different next hop based on IPv4 or IPv6 Access Control List (ACL)
• DHCP Server :Switch functions as an IPv4 DHCP server serving IP addresses for multiple DHCP pools/scopes Support for DHCP options
• DHCP relay at Layer 3 :Relay of DHCP traffic across IP domains
• User Datagram Protocol (UDP) relay :Relay of broadcast information across Layer 3 domains for application discovery or relaying of Bootstrap Protocol (BOOTP)/DHCP packets
• Priority levels :8 hardware queues
• Scheduling :Strict priority and Weighted Round-Robin (WRR)
• Rate limiting :Ingress policer; egress shaping and rate control; per VLAN, per port, and flow based; 2R3C policing
• Congestion avoidance :A TCP congestion avoidance algorithm is required to minimize and prevent global TCP loss synchronization
• iSCSI traffic optimization :A mechanism for giving priority to iSCSI traffic over other types of traffic
• Energy Detect :Automatically turns power off on RJ-45 port when detecting link down. Active mode is resumed without loss of any packets when the switch detects the link up
• Cable length detection :Adjusts the signal strength based on the cable length. Reduces the power consumption for shorter cables.
• EEE Compliant (802.3az) :Supports IEEE 802.3az on all copper Gigabit Ethernet ports
• Disable port LEDs :LEDs can be manually turned off to save on energy
• Time-based port operation :Link up or down based on user-defined schedule (when the port is administratively up)
• Time-based PoE :PoE power can be on or off based on user-defined schedule to save energy
• Jumbo frames :Frame sizes up to 9K bytes. The default MTU is 2K bytes
• MAC table :16K addresses
• USB slot :USB Type-A slot on the front panel of the switch for easy file and image management
• Buttons :Reset button
• Cabling type :Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T
• LEDs :System, Link/Act, PoE, Speed
• Flash :256 MB
• CPU :800 MHz ARM
• DRAM :512 MB
• Storage temperature :-13° to 158°F (-25° to 70°C)
• Operating humidity :10% to 90%, relative, noncondensing
• Storage humidity :10% to 90%, relative, noncondensing
• Warranty :Limited lifetime with next business day advance replacement (where available)
