Cisco ASR 1000 Series Aggregation Services Router/Processor 40Gbps ASR1000-SIP40

Quick spec of ASR1000-SIP40-Ref

• Product Code : ASR1000-SIP40
• Maximum Number of SPAs : 4
• Cisco IOS XE Software Release : Cisco IOS XE Release 2
• Supported Route Processor : ASR1000-RP1 and ASR1000-RP2
• Supported ESP : ASR1000-ESP10, ASR1000-ESP10-N, ASR1000-ESP20, ASR1000-ESP40, and ASR1000-ESP100 Note: ASR1000-ESP100 is supported only on routers on which ASR1000-RP2 is installed.
• Supported Cisco ASR 1000 Router Chassis : Cisco ASR1002, Cisco ASR 1002-F, Cisco ASR 1004, Cisco ASR 1006, and Cisco ASR 1013 Routers

ASR1000-SIP40-Ref Specification

• Physical dimension (HxWxD) :1.630 inches (41.4 mm) x 16.725 inches (424.8 mm) x 14.187 inches (360.3 mm)
• Shipping weight :8.5 lb (3.9 kg)
• Operating temperature :Nominal—40.9 to 104°F (5 to 40°C) Short Term—40.9 to 131°F (5 to 55°C)
• Relative humidity :Operating Humidity Nominal—5% to 85% noncondensing Operating Humidity Short Term—5% to 90% noncondensing
• Storage temperature :–40F to 158F (–40°C to 70°C)
