Arista DCS-7050SX3-96YC8-F 36x40GbE QSFP+ / 18x40GbE 12x100GbE switch router

Arista DCS-7050SX3-96YC8-F 36x40GbE QSFP+ / 18x40GbE 12x100GbE switch router

Overview

The Arista 7050X3 are members of the Arista 7050X series and key components of the Arista portfolio of data center switches. The adoption of high performance servers using virtualization and containers with increasingly higher bandwidth is accelerating the need for dense 25 and 100G Ethernet switching in both the leaf and spine tiers of modern networks. The Arista 7050X3 Series high performance exible data center switches with a rich set of wire speed L2 and L3 features combine extensive automation with programmability, low latency and consistent features for software driven cloud networking. The 7050X3 Series are available in a choice of conguration options. Combining high density and industry leading power e ciency with typical power consumption under 7W per 100GbE port the 7050CX3-32S and 7050CX3-32C are ideal for both high performance leaf or collapsed spine tiers with air ow choices for back to front, or front to back. The Arista 7050SX3-96YC8-F is designed for high-performance data centers, offering flexibility, low latency, and consistent features for software-driven cloud networking. Whether you’re building leaf or collapsed spine tiers, this switch provides the power and efficiency needed for modern networks.

Specifications

• • • 7050SX3-96YC8: 96x SFP25 & 8x QSFP100 ports.
    • Throughput: Up to 6.4 terabits per second.
    • Packet Rate: Up to 2 billion packets per second.
    • Latency: From 800 ns.
  • Data Center Optimized Design:
    • Over 94% efficient power supplies.
    • 1+1 redundant & hot-swappable power.
    • N+1 redundant & hot-swappable fans.
    • Data center optimized airflow.
    • Tool-less rails for simple installation.

Features:

• • High Density Ports:
    • 96 ports of 25G SFP.
    • 8 ports of 100G QSFP.
  • Seamless Migration:
    • Supports migration from 1/10G to 25G.
    • Enables high-density 25G solutions without network oversubscription.
  • Cloud Networking Ready:
    • VXLAN and VM Tracer.
    • OpenFlow, DirectFlow, and eAPI.
    • 288K MAC entries and 360K IPv4 Routes.
    • 168K IPv4 Host Routes.
    • 32 MB integrated intelligent buffer with dynamic buffer allocation.
  • Resilient Control Plane:
    • High-performance x86 CPU.
    • 8 GB or 16 GB DRAM.
    • Advanced Provisioning & Monitoring (CloudVision).
    • Zero Touch Provisioning (ZTP).
    • LANZ for microburst detection.
    • DANZ Advanced Mirroring for visibility.
    • sFlow.
    • Self-configure and recover from USB.
    • Traffic-aware ECMP and UCMP.

Form Factor:

• • 2RU system.
  • 96 ports of 25G and 8 ports of 100G.
  • Overall throughput: 6.4 Tbps bi-directional.

Datasheet
